Metrology

Metrology Laboratory is equipped with latest, accurate & precise machines and equipments. The laboratory having Co-ordinate measuring machine, Surface Roughness tester and Contour Tracer.

Surface Roughness Measurement Machine
Computerized Control Contour Measurement
Digital Height Gauge
Profile Projector with DRO

Precision Measurments

  • Profile Projector with DRO. Viewing Range: 600mm Dia. and Magnification: 100x, Model: P4-600A, Make: Mitutoyo, Japan.
  • Digital Height Gauge. Range: 0-60mm, Model: Vertical-3, Make: TRIMOSS, SWISS.
  • Computerized Control Contour Measurement (Model: Contracer CV2100 M4); x=100 mm; z=50 mm; Column Travel=350 mm, Linearity Accuracy 2.5µm/100mm.
  • Surface Roughness Measurement Machine (Model: SJ-500P), Make: Mitutoyo, Japan; Range: X=50 mm; Z=800 µm, Minimum Resolution: 0.0001µm, Capability; All finishing parameters as per DIN, JIS, IS, ISO & VDA Standards.
